KHS Alite 3000 1996 Technical specs and features
Brand | KHS |
Model | Alite 3000 |
First production | 1996 |
Bike category | Mountain Bike |
Bike sub-category | Mountain Without Suspension |
Bike Pricing | Check price Here ==> |
Parts And Accessories | KHS Alite 3000 Parts |
Available Sizes | - 15 (inches) / 38.1 (cm) - 15 (inches) - 17 (inches) / 43.18 (cm) - 17 (inches) - 19 (inches) / 48.26 (cm) - 19 (inches) - 21 (inches) / 53.34 (cm) - 21 (inches) |
Wheels And Breaking System
Bike front tire | 26 X 1.95 (inches) WTB Primal Raptor |
Bike rear tire | Not Available |
Bike wheel size | 26 (inches) Wheels |
Brakeset type | Dia-Compe PC-7N Levers Shimano STX-RC M-System Brakes |
Hubs for disc brakes | Not Available |
Rims manufacturer | 32-hole Bontrager BCX-2 |
Spoke nipples type | Brass Nipples |
Spoke wheel | 2.0 (millimeters) Straight Gauge Stainless Steel |
Frame and Body Specifications
Frame materials | Easton ProGram Elite Double-butted |
Frame type | Welded Aluminum |
Handlebar construction | Kalloy AL002 |
Handlebar extender | Powertool Forged Alloy |
Handlebar stem details | Hsin Lung TDS-AL-58 |
Headset size | 1 1/8 (inches) Threadless Dia-Compe Kontak Aheadset ST-2 |
Gearing Specs
Bicycle chain | 1/2 X 3/32 (inches) KMC SS-90 |
Bottom bracket shell width | 68 (millimeters) English |
Bottom bracket type | 110 (millimeters) Spindle Shimano BB-UN52 |
Crankset parts and sizes | 22/32/44 Teeth White Industries |
Gear shift levers | Grip Shift SRT-800 X-Ray |
Rear gear set | 11 - 28 Teeth 8-speed |
KHS Alite 3000 Fork System Data
Derailleur (Front) | Top-pull Shimano Deore LX |
Derailleur (Rear) | Shimano Deore LX SGS |
Fork material | Triple-butted Unicrown Crown Chromoly |
Fork type | Spinner |
Other Specs of KHS Alite 3000
Component group sets | Shimano Deore LX |
Available colors | - Cabernet and titanium color |
Weight | 22.9 |
Pedals details | Fasten NWL-90K With Clips & Straps |
Rear shock absorber | Not Available |
Saddle seat | Selle San Marco Tecno Dynamica |
Seat post extension | 26.8 (millimeters) Diameter Polygon PM-312 |
KHS Alite 3000 picture
Alite 3000 bike comparison
KHS Alite 3000 Fuji Suncrest

KHS Alite 3000 Scott Tigua
KHS Alite 3000 Miele Mercury

KHS Alite 3000 Mongoose Threshold
KHS Alite 3000 bike review
KHS produced the Alite 3000 bike in 1996 and can be classified as a Mountain bike bicycle, this exact model costs in american market arround $999.00.
Alite 3000 bike is available in many sizes such as 15 (inches), 17 (inches), 19 (inches) and 21 (inches).
KHS Mountain bike Alite 3000 can be found in a few colors, among these colors Cabernet and titanium color .
This bike is equiped with 26 x 1.95" WTB Primal Raptor tires and Stainless steel spoke wheel while the rims are manufactured by Bontrager BCX-2, 32-hole. KHS equiped this exact model with Shimano STX-RC M-System brakes, Dia-Compe PC-7N levers braking system .
To guarantee the comfiest ride KHS used Easton ProGram Elite double-butted material for the frame. Kalloy AL002 high strength material is used on the handlebar of this Alite 3000 to ensure the perfect handling while the stems are made of Hsin Lung TDS-AL-58.
For the smoothest biking experience White Industries, 22/32/44 teeth is used on this bicycle linked to KMC SS-90 chain that is easily replaceable as stated by KHS, the whole system is connected to a high reliability Grip Shift SRT-800 X-Ray gear shift levers.
